Ferrari Scuderia Spider 16M
The Ferrari Scuderia Spider 16M has been created with the goal of bringing together superb performance and the pleasure of driving in the open air. The result is the best-performing spider ever created by Ferrari, a car which evokes the emotions of the barchetta models that were the protagonists of the great multi-stage races of the 1950s. The car's technological solutions, make the most of the latest innovations in the 430 Scuderia, derived from Formula 1, to guarantee uncompromising handling on the road. This is reflected in the name, which is also connected to Formula 1: a celebration of the 16 World Constructors' Titles Ferrari have won. The Scuderia Spider 16M is a marriage of performance and driving pleasure produced in a special, limited edition for only 499 passionate customers.
PERFORMANCE
The Ferrari Scuderia Spider 16M offers technological solutions that have already been tested on the 430 Scuderia. It's an ultra-high-performance car (0-100 km/h in 3.7 seconds) designed for fast, tight driving conditions with a set-up that highlights sports driving and that offers all the enjoyment of open-top driving in the F430 Spider. In tests at the Fiorano circuit the car recorded lap times lower than any other Ferrari spider model designed for the road.
WEIGHT/ POWER
The Ferrari Scuderia Spider 16M weighs 80 kg less than the F430 Spider (dry weight 1340 kg) and many details were revised and designed with this specific goal in mind. The most significant changes were made on the chassis and on the body, much use has been made of light materials and carbon fiber. All this has made it possible to achieve a first-in-class power-to-weight ratio of 5.8 lb/CV.
ENGINE
The Ferrari Scuderia Spider 16M's engine, like the 430 Scuderia's, is an evolution of the F430's 4.3-litre V8. It features a number of modifications designed to boost performance and raise specific power to 118 CV/l, equal to a total power output of 510 CV, while complying with the strict limits on exhaust emissions established in the Euro4 and LEV2 standards.
SOUND
Engine sound is a distinctive characteristic of all Ferraris and has always been a fundamental element in creating a strong connection with the driver through increased feedback and driving satisfaction. This is achieved by paying special attention to the level and to the quality of sound, in order to ensure perfect acoustic comfort under any conditions.
GEARBOX
The F1-SuperFast2 gearbox is the latest evolution derived from Formula 1: a totally innovative integrated engine and gearbox management programme allows the combined disengaging/engaging of the gears to take place in parallel with letting the clutch in and out. As a result, gear-change time has been even further reduced to 60 milliseconds.
E-DIFF
In use in Formula 1 for a number of years, E-Diff has been integrated with the car's stability control systems. Torque is intelligently distributed to the wheels by the hydraulic actuation of two sets of friction discs and their connected reaction discs. The amount of torque delivered depends on driving conditions, modifying the effect of the differential and bringing considerable advantages in terms of performance, directional stability, active safety and driving pleasure. E-Diff is integrated with the car's other systems and allows the driver to change the set-up according to road-holding conditions from the steering wheel-mounted manettino.
F1-TRAC
F1-Trac, like E-Diff, is the traction control system directly derived from the experience of Formula 1 cars. The system guarantees maximum traction on exiting corners, stability and ease of driving even in extreme conditions, consistent performance, and drive comfort. The advantage of the combination of E-Diff and F1-Trac compared to conventional systems of stability and traction control is shown by a 40% increase in acceleration out of corners.
RACING MANETTINO
The Ferrari Scuderia Spider 16M uses the Racing version of the manettino, which puts the emphasis on sporty driving and offers more options for configuration of the parameters of the car's electronic controls. The ICE setting used on the F430 has been replaced by the CT position. This deactivates only traction control, leaving stability control in operation.
CARBON CERAMIC BRAKES
The Ferrari Scuderia Spider 16M's braking system with carbon ceramic discs has resulted in an overall improvement in braking performance compared to that of the F430's system, from which it is derived. The front discs with their larger diameter allow an improved rolling radius and hence greater braking efficiency. The front brake pads are specific to the car and allow improved dissipation of the heat produced by higher performance. They are also more hard-wearing. The brake pedal feel has been optimized for all driving conditions and remains consistent even in extreme situations on the racetrack.
STYLE AND AERODYNAMICS
Traditionally, the styling of a Ferrari has been created around the forms dictated by the car's engineering, with the aim of obtaining maximum aerodynamic efficiency. The Ferrari Scuderia Spider 16M's high performance and dynamics required a reinterpretation of numerous elements of both internal and external styling. The objective was to style the car through those aerodynamic features necessary for a car designed with the highest levels of performance in mind. Since the 16M is a Spider, the design kept in mind the needs of driving with the top down and of the pleasure this should provide. External styling has been enhanced with numerous details in carbon (front fin, rear-view mirror, headlight housing, diffuser, roll bar) as well as new colours in metallic black body and dark grey wheel rims. A new livery emphasises the lines of the car.
AUDIO EQUIPMENT
A new audio system of the latest-generation has been created for the Ferrari Scuderia Spider 16M. The hi-fidelity has an 8x50 watt amplifier consisting of two woofers, two midrange speakers and two tweeters integrated in the carbon door panel. The multimedia interface offers a removable Ferrari-personalised 16GB iPod® Touch housed in the centre of the instrument panel. Alternatively, a Becker® Cascade radio with Bluetooth and iPod® connection is available.23
PERSONALISATION
The Ferrari personalisation programme has been enhanced and matched to the special features of the car. The programme has four separate areas: Racing and Track, Exterior and Colours; Interior and Materials, Equipment and Travel.In the Interior and Materials area it is possible to select Poltrona Frau® leather as an alternative to technical fibre or Alcantara®. And for this limited edition car there is also a special set of soft travel bags, a satellite anti-theft system and satellite navigation. It is also possible to select a "tricolore" livery in the colours of the italian flag.
Technical Specifications
- Engine
- Naturally aspirated mid-rear 90° V8, 4308 cc
- Maximum power: 375.4 kW (510 hp) @ 8500 rpm
- Maximum torque: 470 Nm (47.7 Kgm) @ 5250 rpm
- Max engine speed: 8640 rpm (at limiter)
- Compression ratio: 11.9:1
- Bore and Stroke: 92 mm X 81 mm
- Specific power output: 118.4 hp/litre
- Transmission
- Six-speed plus Reverse F1 gearbox
- Dry dual clutch
- Electronic differential E-diff + F1-Trac
- Oil gearbox lubrication with oil/water heat exchanger
- Performance
- 0-100 km/h: 3.7 s
- Top speed: 315 kph
- Drive weight/power: 2.6 kg/hp
- Fuel consumption
- Combined: 15.7 l/100 km (ECE)
- Emissions
- CO2 emissions: 360 g/km (combined ECE)
- Chassis and bodywork
- Dimensions
- Length: 4512 mm
- Width: 1923 mm
- Height: 1216 mm
- Wheelbase: 2600 mm
- Front track: 1669 mm
- Rear track: 1616 mm
- Dry weight: 1340 kg
- Kerb weight: 1440 kg
- Weight distribution: 43% front, 57% rear
- Fuel tank capacity: 95 litres
- Independent front and rear forged aluminium double wishbone suspensions, titanium helical springs, hollow anti-roll bars and lighter electronic shocks
- Brakes
- Front: 398 mm x 36 mm carbon-ceramic material disc brakes with aluminium 6-pot callipers
- Back: 350 mm x 34 mm carbon-ceramic material disc brakes with aluminium 6-pot callipers
- 19" five-spoke split rims front and rear
- Tyres: 235/35 front and 285/35 rear; Fabbrica Pirelli PZero Corsa only
- Electronic control systems
- CST Stability and Traction Control System
- Steering wheel-mounted manettino with five settings to integrate the F1 gearbox, CST and F1-Trac (Stability and Traction Control System), suspension control.
